AV-2TQ Thin Ball Valve Q01.1
Availability :
In stock
| Size | DN 15-65 |
| Working temperature | -20 to 120℃ |
| Working pressure | 1.6MPa |
| Body material | CF8, CF8M |
| Sealing material | PTFE |
| Connection | Flange |
Thin Ball Valve Q01.1 Description
Thin Ball Valve Q01.1 is designed to be of fireproof and anti-static structure. It is also designed to be of integrated structure to reduce the number of leakage points and require less space for installation.
Thin Ball Valve Q01.1 Specifications
| Size | DN 15-65 |
| Working temperature | -20 to 120℃ |
| Working pressure | 1.6MPa |
| Body material | CF8, CF8M |
| Sealing material | PTFE |
| Connection | Flange |
Thin Ball Valve Q01.1 Applications
Thin Ball Valve Q01.1 is suitable for a general medium such as water, steam, oil, nitric acid, acetic acid, oxidizing medium, urea and other media.
Related products: AV-1HMU High-Performance Manual Ultra-Thin Ball Valve With Flange Connection, AV-2BVP BRASS V-PORT BALL VALVE, AV-2TB 11100 SERIES TRUNNION BALL VALVE, AV-10MB SANITARY TANK BOTTOM BALL VALVE WITH TRI-CLAMP ENDS, MANUAL TYPE, AV-2MCC SANITARY CAVITY FILLED BALL VALVE WITH TRI-CLAMP ENDS, MANUAL TYPE
