AV-7YS Yogurt Sampling Valves
Material: 316L Temperature: 130℃ Pressure: 10bar
AV-8 Sanitary Constant Pressure Valves
Working temperature -10 to 150 °C Working pressure 8 bar Body material 304/316L Sealing material EPDM + PTFE (FDA177.2600) Connection Clamp, thread, welding Finishing Ra< 0.6µm Standards ISO, DIN, SMS, RJT
AV-8M Mini-Type Constant Pressure Valve
Specifications: Size 3/4"-1.25",DN20-DN32 KV value 10-21m³/h Working temperature -10 to 150 °C Working pressure 8 bar Max working pressure 12 bar (option) Body material 316L/304 Sealing material EPDM+PTFE(FDA177.2600) Connection Clamp, thread, weld Finishing Inside Ra≤0.6 μm Standards ISO, DIN, SMS, RJT
AV-8P Sanitary Plate Heat Exchanger
Specifications: Plate Material: 304 or 316L Body Material: 304 Gasket Material: NBR, EPDM, etc Max Working Pressure: 3Mpa Working temperature: -10℃ - +150℃ Cooling: Single stage or two stages Size: 1m², 3m², 5m², 7m², 10m² Plate Material: 304 or 316L
AV-9A Sanitary Air Relief Valve
Reference No.: AV-9A Sizes: 1"-2", DN25-DN50 Material: 316L Gasket: EPDM, Silicon, Viton Ball: PP, PTFE PSI: 145psi (10Bar) Maximum Operating temperature: 194°F (maximum)
AV-9E Sanitary Threaded Safety Exhaust Valve with Glass Window
Specifications Size 0.75”-1.5” Max working temperature 121°C Working pressure 0-3bar/ 0-6bar Body material 304/316L Sealing material EPDM, NBR, FPM Connection Clamp, welded, threaded, flange Standards DIN, SMS, RJT, IDF, 3A
AV-9FW Sanitary Four-way Safety Valve
Materials: 304/316L Size: 1"-4", DN25-DN100 Max Temp. : 130℃ Set Pressure: (0-3bar/0-6bar/6-10bar) KV Value: 8.5-180m3/h
AV-9HP Sanitary High Purity Pressure Reducing Valve
Media: steam, liquid, gas Size: 1"-3", DN25-DN80 Max Temp. : 180℃ Nominal pressure: PN2.5-10 Inlet pressure: 8bar Outlet pressure: 0.3-5bar KV Value: 4-70m3/h Connection mode: Clamps, welding, thread, Flange
