Adamant Valves manufacturer
Adamant Valves manufactures a wide range of stainless steel sanitary valves and fittings, and delivers high performance and outstanding value in sanitary applications.
Adamant Valves has a vast selection of stainless steel, carbon steel, cast iron, brass, PVC in 2-way, 3-way, 4/5-way configurations and special purpose valves (for high pressure and high temperature valves).
AV-10 Sanitary Tank Bottom Valves
Materials Product wetted steel parts: AISI 316L/304 Other steel parts: AISI 304 FDA Seal: EPDM Optional: PTFE, all seals complying with FDA 21CFR177.2600. Technical Specification: Max. working pressure: 147psi (10bar) Control air pressure: 70-116 (5-8bar) Working temperature range: EPDM: 14° F to 248° F (-10°...
AV-10BM Sanitary Tank Bottom Diaphragm Valve, Manual Type
Technical Specification: Size: 1”-4” DN25-DN100 Max. working pressure: 145psi (10bar) Working temperature range: -4° F to 302° F (-20°C to 150°C) Sterilization temperature: 302° F ( 150° C, MAX 20 min) Finish: <32Ra (<0.8 µm) Other finishes available upon request
AV-10BP Sanitary Tank Bottom Diaphragm Valve
Technical Specification: Size:1”-4” DN25-DN100 Max. pressure: 116psi (8bar) Control air pressure: 70-116 (5-8bar) Highest temperature range: Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to 130°C)...
AV-10MB Sanitary Tank Bottom Ball Valve With Tri-Clamp Ends, Manual Type
Specification: Size 1"-4"/DN25-DN100 Working pressure 0-10 bar (145psi) Outside surface Matte, light, sandblast and electronic polishing Body Material AISI 316L / AISI 304 Working temperature Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to...
AV-10MCB Multi-channel Bottom Diaphragm Valve
Multi-channel bottom diaphragm valve MG-32B Size: 1"-2", DN25-DN50 Material: 316L/1.4404, 1.4435 NB2 Fe＜5% Operations: Manual/Pneumatic Control: configurable, 1) Control Unit C-TOP, 2) positioner IL-TOP, 3) mechanical valve regulator, 4) Position Sensor
AV-10PB Sanitary Tank Bottom Ball Valve With Tri-Clamp Ends, Pneumatic Type
Specification: Size 1"-4"/DN25-DN100 Working pressure 0-10 bar (145psi) Outside surface Matte, light, sandblast and electronic polishing Body Material AISI 316L / AISI 304 Working temperature Stainless steel actuator: -12° F to 302° F (-20°C to 150°C) Plastic actuator: -12° F to 266° F (-20°C to...
AV-10PD Sanitary Pneumatic 2-way Double Seat Mix Proof Valve with Welded End
Specifications Size 1.5”-4”, DN40-DN100 Working temperature -10 °C ~130 °C Working pressure 0-10 bar Body material 304,316L Sealing material Viton, Silicone Connection Butt-welded, sanitary clamp, threaded, flange, DIN, SMS, RJT, IDF, or others upon request. Finishing <32Ra (<0.8µm); Other finishes available upon request.
AV-10TB Tank Bottom Valve
Features: Complete discharge system avoided retention. Normally closed valve(closed by spring)-standard version. Normally open valve(opened by spring)by a 180 degree rotating of the pneumatic actuator. 360° adjustable body, even after welding the flange to the tank. Easy maintenance and low maintenance cost by tri-clamp. FDA-approved...
AV-11A Stainless Steel Pneumatic Actuator
Materials Steel parts: AISI 304 Seal: VMQ/FPM/EPDM Standard Design: Vertical type with stainless steel 304 material Three types available: Normally closed (NC)-Air to open and spring to close; Normally open (NO)-Air to close and spring to open; Air to Air (AA)-Air to open air to...
