AV-4VG 4-position 4-way Titanium Diaphragm Valve G0944.1
Size 3/4"-2.5", DN20-DN65 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Outlet Connection Clamp, weld, Special interface Working Temp. -20 to 120℃ Max. pressure 10 bar
AV-4WD 2-position 3-way Titanium Diaphragm Valve G0923.3
Size 1/4”-3/4”, DN6-DN15 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, thread, flange, etc. Working Temp. -20 to 150℃ Set pressure 10 bar
AV-4WG 4-position 5-way Titanium Diaphragm Valve G0945.2
Size 3/4"-2.5", DN20-DN65 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Outlet Connection Clamp, weld, Special interface Working Temp. -20 to 120℃ Max. pressure 10 bar
AV-4WT 3-position 3-way Titanium Diaphragm Valve G0933.1
Materials: Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Size: 1"-4", DN25-DN100 Working Temp. : -20 to 150℃ Set Pressure: 10 bar Connection clamp: clamp, welding, and other special connection
AV-4WV 4-position 4-way Titanium Diaphragm Valve G0944.4
Size 1/4”-3/4”, DN6-DN15 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, thread, flange, etc. Working Temp. -20 to 150℃ Set pressure 10 bar
AV-5AJ Sanitary Titanium Pneumatic Clamp Angle Seat Valve J02.3
Size DN10~DN80 Working temperature -20 to 120℃ Working pressure 0-2.5Mpa Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Sealing material PTFE Connection Clamp
AV-5AR Sanitary Titanium Angle Seat Valve (Responder) J02.5
Size DN25-DN100 Working temperature -30 to 180℃ Working pressure vacuum to 10 bar Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Sealing material PTFE Connection clamp, thread, weld, flange, DIN SMS RJT ISO
AV-5AS Sanitary Pneumatic Angle Seat Valves
Materials Materials: AISI-316L Size: 1/2''-2 1/2'' Valve plug and seal: Teflon (PTFE) Design Features Size: 1/2”, DN15 - DN80 Material: CF8/304, CF8M/316 Connection: Thread, clamp, flange, BSP, BSPT, NPT, DIN, or other upon request. Working pressure: 8bar, 10bar Working temperature: 120℃, 180℃
AV-5BP Back Pressure Regulator BPR01
Working temperature -40 to 204℃ Operating Conditions 0-500 psig (0-35.0 barg) Body material 316L Stainless Steel, Monel, Or Hastelloy C-22 Sealing material Teflon Connection 1/8” or 1/4” female pipe threads,
