AV-3P Three Piece Check Valve
Casing/Shaft: AISI 316L/AlSI 304 Spring: AISI 301 Surface Finishing: Ra≤0.8μm Max. Pressure: 0.3bar (DN25) 0.2bar (DN32/40) 0.1bar (DN20/100) Operating Temp. : -10℃ to +120℃ (EPDM)
AV-3S High Performance Swing Check Valve
Specifications: Size DN 2-12 Working temperature -10 ~ 110°C Working pressure 16 Bar Max. Body material 316 L/ aluminum bronze Sealing material NBR
AV-3T Sanitary Check Valve with Thread Ends
Specification: Sizes are available from 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve body can be AISI 304 or AISI 316L. Valve seat: EPDM, VMQ (silicone), Viton (FPM)...
AV-3TC Sanitary Spring Check Valves with Tri-Clamp
Specifications Size 1”, 1.5”, 2”, 2.5”, 3”, 4” Max. working temperature 140°C Max. working pressure 10 Bar Body material 316L/304 Sealing material VITON, SILICON,EPDM Connection Welded, thread, clamp Finishing Ra<0.8μm Standards ISO/DIN/ASME BPE/3A/BS/GB
AV-3W Sanitary Check Valve with Butt-weld Ends
Specification: Sizes are available from 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve body can be AISI 304 or AISI 316L. Valve seat: EPDM, VMQ (silicone), Viton (FPM)...
AV-4AT Aseptic Tank Bottom Diaphragm Valve G15
Size 3/4"-2.5", DN20-DN65 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Outlet Connection Clamp, weld, Special interface Working Temp. -20 to 120℃ Max. pressure 10 bar
AV-4BD Tank Bottom Diaphragm Valve G04
Size 1”-4” DN25-DN100 Body material Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Connection Clamp, welding, flange Working Temp. 302℉ ( 150℃, MAX 20 min) Max. Working pressure 10 bar
AV-4BG Pneumatic Tank Bottom Titanium Diaphragm Valve G04
Size: 1″-2″, DN25-DN50 Material: Hastelloy C276/C22 Monel 400, 254SMO N08904 Titanium TA1/TA2 Max. working pressure: 145psi (10bar) Working temperature range: -22 ~ 266℉(-30 ~ 130℃) or higher upon request Inside treatment: Ra 16-32μin (0.4-0.8μm), Ra 25 (0.5μm) is the default.
AV-4BMC Sanitary Diaphragm Bleed Valve With Tri-clamp Ends, Manual Type
Specification Type Diaphragm Sampling Valve Reference No. AV-4BMC Sizes 1/2" to 4" (1/2", 3/4", 1”, 1 1/2", 2", 2 1/2", 3", 4") Diameter Nominal DN15 to DN100 (DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100) Valve material Body: cast iron, ductile iron, carbon steel, 316L,...
