AV-13M Sanitary Manhole
Availability :
In stock
Sanitary Manhole is available in the following 7 types. They are mainly used in a variety of food, wine, beverage, pharmaceutical, and other industrial fields of pressure vessels.
A Hole Glass Manhole Cover: AV-13M-A
The whole glass manhole is mainly used in a variety of food, wine, beverage, pharmaceutical and other industrial fields of pressure vessels.
- All glass manhole cover
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- Working pressure: 2-5 bar
- Size:200 mm, 220 mm, 300 mm, 350 mm, 400 mm, 430 mm, 450 mm, 500 mm, 600 mm
- Height:100 mm, 120 mm, 150 mm
- Gasket: EPDM, NBR, Silicon
- Material: AISI304/316L
- The number of hand wheel can be adjusted
B 316L Manhole Cover: AV-13M-B
The stainless steel manhole cover is mainly used for pressure vessel in the fields of food, wine, beverage, pharmaceutical, etc.
- Outward opening manhole cover
- Plastic wheel or stainless steel hand wheel
- Sight glass with flange
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface: polishing finished and sand-blasting finished
- Working pressure: 10 bar
- Size:400 mm, 430 mm, 450 mm, 500 mm, 600 mm, 800 mm, 900 mm
- Height:100 mm, 120 mm, 150 mm
- Gasket: EPDM, NBR, Silicon, FPM
- Material: AISI304/316L
- The number of hand wheel can be adjusted
C Pressure manhole with Sight glass: AV-13M-C
The stainless steel manhole cover is mainly used for pressure vessel in the fields of food, wine, beverage, pharmaceutical, etc.
- Outward opening manhole cover
- Plastic and wheel or stainless steel hand wheel
- Sight glass with flange
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface: polishing finished and sand-blasting finished
- Working pressure: 10 bar
- Size:400 mm, 430 mm, 450 mm, 500 mm, 600 mm, 800 mm, 900 mm
- Height:100 mm, 120 mm, 150 mm
- Gasket: EPDM, NBR, Silicon, FPM
- Material: AISI304/316L
- The number of hand wheel can be adjusted
D Pressure Round Manhole: AV-13M-D
The whole glass manhole is mainly used in a variety of food, wine, beverage, pharmaceutical and other industrial fields of pressure vessels.
- All glass manhole cover
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- Working pressure: 2-5 bar
- Size:300 mm, 350 mm, 400 mm, 450 mm, 500 mm, 600 mm, 800 mm
- Height:100 mm, 120 mm, 150 mm
- Gasket: EPDM, NBR, Silicon
- Material: AISI304/316L
- The number of hand wheel can be adjusted
E Round Manhole: AV-13M-E
The whole glass manhole is mainly used in a variety of food, wine, beverage, pharmaceutical and other industrial fields of pressure vessels.
- Outward opening manhole cover
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- Working pressure: 2-5 bar
- Size:300 mm, 350 mm, 400 mm, 450 mm, 500 mm, 600 mm, 800 mm
- Height:100 mm, 120 mm, 150 mm
- Gasket: EPDM, NBR, Silicon, FPM
- Material: AISI304/316L
F Elliptical Manhole: AV-13M-F
The manhole cover is mainly used for tanks in the fields of food, beverage, chemical, etc.
- Inward opening manhole cover
- Spanner handle or wheel handle
- Size: 435*335 mm, 530*335 mm, 635*525 mm
- Internal surface treatment: Ra 0.5μm-0.8μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- Working pressure: 0.5-3.0 bar
- Height:75 mm, 100 mm, 120 mm, 150 mm
- Material: AISI304/316L
G Square Hand Hole: AV-13M-G1
The Square Hand Hole is square-shaped with an open lid, mainly used in food, wine, beverage, pharmaceutical and other industrial tank equipment.
- Spanner type handle, wheel handle
- Internal surface treatment: Ra 0.5 μm-0.8 μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- pressure: 0.2-1.0 bar (pressure square hand hole is also available)
- Gasket: EPDM, NBR, Silicon, FPM
- Height:65 mm, 80 mm, 100 mm, 120 mm, 150 mm
- Material: AISI304/316L
G Square Hand Hole: AV-13M-G2
The Square Hand Hole is square-shaped with an open lid, mainly used in food, wine, beverage, pharmaceutical and other industrial tank equipment.
- Spanner type handle, wheel handle
- Internal surface treatment: Ra 0.5 μm-0.8 μm
- Outside surface treatment: Mirror polish, Satin finish, sanding-blasting finished
- pressure: 0.2-1.0 bar (pressure square hand hole is also available)
- Gasket: EPDM, NBR, Silicon, FPM
- Height:65 mm, 80 mm, 100 mm, 120 mm, 150 mm
- Material: AISI304/316L
